The Isco 5800 Refrigerated Sampler is a definite purpose device designed for water quality and industrial applications‚ offering precise sample collection with advanced features.
1.1 Overview of the Device and Its Purpose
The Isco 5800 Refrigerated Sampler is a sophisticated device designed for water quality monitoring‚ enabling precise and reliable sample collection. It supports both composite and sequential sampling methods‚ making it versatile for various applications. The sampler is built to maintain sample integrity with temperature control‚ ensuring accuracy in laboratory analysis. It is specifically intended for use with compatible Teledyne ISCO equipment‚ adhering to safety and operational standards.
1.2 Key Features of the Isco 5800
The Isco 5800 features a control panel for user-friendly operation and programming‚ with a secure cover to protect settings. It includes a discharge tube for directing samples and operates in a wide temperature range of -20°F to 120°F (-29°C to 49°C). The device supports both composite and sequential sampling modes‚ enhancing flexibility for diverse applications. Additionally‚ it integrates seamlessly with Teledyne ISCO equipment for optimal performance.
Installation and Setup
The Isco 5800 requires careful installation‚ starting with attaching the suction line to the pump tubing and connecting to associated components like the relay alarm box.
2.1 Step-by-Step Installation Guide
Begin by attaching the suction line to the pump tubing‚ ensuring a secure connection to avoid leaks. Next‚ mount the sampler and associated components like the relay alarm box and 3-way actuated ball valve on an aluminum plate. For pressures exceeding 15 psi‚ install a pressure reduction valve. Connect the flow meter cable to the sampler‚ ensuring compatibility with Teledyne ISCO equipment. Finally‚ power up the system and test all connections to ensure proper functionality.
2.2 Mounting the Sampler and Associated Components
Mount the Isco 5800 sampler and its components on a sturdy aluminum plate to ensure stability. Secure the relay alarm box and 3-way actuated ball valve alongside the sampler. For pressures above 15 psi‚ install a pressure reduction valve to prevent system damage. Ensure all connections are tight and properly aligned to maintain optimal performance and safety during operation.
Operating the Isco 5800
The Isco 5800 operates via an intuitive control panel‚ enabling users to program sampling schedules and monitor operations. It supports both composite and sequential sampling modes for flexible data collection.
3.1 Control Panel Functions and Programming
The Isco 5800 features a user-friendly control panel with a keypad and display for easy operation. The control panel cover protects the display and can be locked with a user-supplied padlock for security. Programming options allow users to set sampling intervals‚ durations‚ and modes (composite or sequential). The system supports advanced customization of sampling parameters‚ ensuring precise and automated sample collection based on specific requirements.
3.2 Composite vs. Sequential Sampling Modes
The Isco 5800 offers two sampling modes: composite and sequential. Composite mode combines multiple samples into one bottle‚ providing an average concentration over time. Sequential mode fills each bottle with a distinct sample‚ capturing variations at specific intervals. Both modes are programmable via the control panel‚ allowing users to tailor sampling to their monitoring needs for accurate and reliable data collection.
Maintenance and Troubleshooting
Regular maintenance ensures optimal performance‚ including pump inspection‚ tubing checks‚ and refrigeration system verification. Troubleshooting addresses common issues like blockages or temperature fluctuations‚ requiring cleaning or adjustment.
4.1 Routine Maintenance Tasks
Routine maintenance for the Isco 5800 involves regular inspection of the pump‚ tubing‚ and refrigeration system to ensure optimal performance. Cleaning or replacing worn components‚ such as seals or filters‚ is essential. Additionally‚ checking the refrigeration system for proper temperature control and verifying software updates are crucial for maintaining functionality. Regularly documenting maintenance activities ensures compliance and prolongs the sampler’s operational lifespan.
4.2 Common Issues and Solutions
Common issues with the Isco 5800 include tubing damage‚ improper refrigeration‚ and software glitches. Solutions involve inspecting and replacing damaged tubing‚ ensuring proper refrigeration settings‚ and performing software updates. Regular maintenance‚ such as cleaning components and checking connections‚ can prevent these issues. Referencing the manual or contacting support for complex problems ensures optimal functionality and extends the sampler’s lifespan.
Safety Information and Precautions
Adhere to safety guidelines to prevent hazards. Use only compatible equipment and follow manual instructions to ensure safe operation and avoid unintended risks.
5.1 General Safety Guidelines
Adhere to safety guidelines to ensure safe operation. Use only compatible equipment and follow manual instructions. Avoid unauthorized modifications or connections. Never operate the sampler near flammable materials or in hazardous environments. Ensure proper grounding and electrical connections. Wear protective gear when handling potentially hazardous samples. Regularly inspect components for damage. Follow all warning labels and instructions provided in the manual to minimize risks and ensure compliance with safety standards.
5.2 Hazard Severity Levels and Alerts
The Isco 5800 uses hazard severity levels to indicate potential risks. Danger signifies immediate hazards that could cause serious injury or death. Warning indicates potential injury or equipment damage. Caution highlights minor hazards or property damage risks. Notice provides important operational information. Always follow these alerts and refer to the manual for specific instructions to ensure safe operation and compliance with safety standards.
Software Updates and Programming
The Isco 5800 supports software updates to enhance functionality and performance. Regular updates ensure compatibility and improve operational efficiency‚ maintaining optimal sampling accuracy and reliability.
6.1 Updating the Sampler Software
To update the Isco 5800 software‚ download the latest version from the manufacturer’s website. Transfer the update to a USB drive and insert it into the sampler. Navigate to the software update section in the menu‚ select the USB drive‚ and follow on-screen instructions. Ensure the device is powered on and avoid interrupting the update process. Restart the sampler after completion to apply changes.
6.2 Customizing Sampling Parameters
Customizing sampling parameters on the Isco 5800 allows users to tailor operations to specific requirements. Use the control panel to program sampling intervals‚ modes‚ and durations. Adjust flow rates and sample volumes as needed; Enable or disable features like refrigeration and alarms. For advanced customization‚ connect to external devices or use software tools. Always validate settings in the manual to ensure proper function and accuracy.
Connecting the Sampler to Other Devices
The Isco 5800 connects seamlessly to flow meters and external analog devices via compatible cables‚ ensuring accurate data transfer and integrated system operation for precise sampling control.
7.1 Flow Meter Integration
The Isco 5800 can be integrated with flow meters to monitor and control sampling operations. Compatible models include Teledyne ISCO 2108 and accQcomm analog output modules. The flow meter cable connects to the sampler’s control panel‚ enabling precise flow rate measurement and synchronized sampling. This setup ensures accurate data collection and seamless operation in water quality monitoring applications.
7.2 Connecting to External Analog Devices
The Isco 5800 can connect to external analog devices via a 4-20 mA signal‚ enabling integration with third-party equipment. This feature allows the sampler to receive input from devices like Teledyne ISCO 2108 or accQcomm modules. The connection is facilitated through a dedicated port on the control panel‚ ensuring compatibility and expanding the sampler’s functionality for diverse monitoring applications.
Refrigeration and Temperature Control
The Isco 5800 maintains consistent refrigeration to preserve sample integrity‚ operating within a range of -20°F to 120°F (-29°C to 49°C)‚ ideal for water quality applications.
8.1 Operating Temperature Range
The Isco 5800 Refrigerated Sampler operates effectively within a temperature range of -20°F to 120°F (-29°C to 49°C)‚ ensuring optimal sample preservation without the need for additional heaters. This wide range makes it suitable for diverse environmental conditions‚ maintaining consistent refrigeration to protect samples from degradation.
8.2 Maintaining Proper Refrigeration
Regular inspection of the refrigeration system is crucial to ensure optimal performance. Check the compressor‚ condenser‚ and evaporator for dust or blockages. Ensure proper airflow around the unit to maintain efficient cooling. Defrost the evaporator as needed and verify refrigerant levels. Perform routine checks on door seals to prevent temperature fluctuations. Follow the manual’s guidelines for maintenance to uphold sample integrity and extend the system’s lifespan.
Compliance and Regulatory Considerations
The Isco 5800 must be used with compatible Teledyne ISCO equipment only‚ as per the manual‚ to ensure adherence to safety standards and regulatory requirements.
9.1 Compatibility with Teledyne ISCO Equipment
Ensure the Isco 5800 is exclusively used with approved Teledyne ISCO devices to maintain operational integrity. Compatibility guarantees optimal performance and safety‚ adhering to the manufacturer’s specifications. Using non-compatible equipment may void the warranty and pose safety risks‚ as stated in the manual. Proper integration ensures compliance with regulatory standards and ensures reliable sampling operations.
9.2 Adherence to Safety Standards
The Isco 5800 Refrigerated Sampler is designed to comply with industry safety standards‚ ensuring safe operation in various environments. It features hazard severity levels‚ including CAUTION and WARNING alerts‚ to guide users on potential risks and proper handling procedures.
Always follow the manual’s safety guidelines to prevent hazards. Proper installation‚ maintenance‚ and operation are critical to ensure compliance and user safety‚ aligning with regulatory requirements and best practices for industrial equipment.
The Isco 5800 Refrigerated Sampler is a robust‚ reliable device designed for precise water quality monitoring. Its advanced features‚ including composite and sequential sampling modes‚ make it ideal for industrial and environmental applications. With proper installation‚ maintenance‚ and adherence to safety standards‚ the sampler ensures accurate and efficient sample collection. Teledyne ISCO’s commitment to quality and customer support further enhances its value. Regular software updates and adherence to manual guidelines are essential for optimal performance.
